Ships in 6-8 Weeks
1ED020I12B2XUMA1
Datasheet
1MB
Specifications
| Digi-Key Part Number | 1ED020I12B2XUMA1TR-ND – Tape & Reel (TR) |
| 1ED020I12B2XUMA1CT-ND – Cut Tape (CT) | |
| 1ED020I12B2XUMA1DKR-ND – Digi-Reel® | |
| Manufacturer | Infineon Technologies |
| Manufacturer Product Number | 1ED020I12B2XUMA1 |
| Description | IC IGBT DVR 1200V 2A DSO16 |
| Detailed Description | Gate Driver Magnetic Coupling 4500Vrms 1 Channel PG-DSO-16-15 |
| Category | Isolators |
| Isolators – Gate Drivers | |
| Mfr | Infineon Technologies |
| Series | EiceDriver™ |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Technology | Magnetic Coupling |
| Number of Channels | 1 |
| Voltage – Isolation | 4500Vrms |
| Propagation Delay tpLH / tpHL (Max) | – |
| Pulse Width Distortion (Max) | – |
| Rise / Fall Time (Typ) | 30ns, 50ns |
| Current – Output High, Low | 2A, 2A |
| Current – Peak Output | – |
| Voltage – Forward (Vf) (Typ) | – |
| Voltage – Output Supply | 13V ~ 20V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295″, 7.50mm Width) |
| Supplier Device Package | PG-DSO-16-15 |
| Base Product Number | 1ED020 |
